Somfy Dexxo Compact 600 RTS

Garage door opener specifications:

Max garage door height depends on boom selected
Max garage door surface 7 m²

Included:

Two handsets

SKU: SOO9700 Categories: Garage Door Openers, Manufacturers, New Products, Products, Somfy, Somfy, SWS SeceuroGlide Tag: Bulky

Description
Features
Additional Technical Information
Downloads

Description

Somfy Dexxo Compact 600 RTS

The perfect solution for smaller garage doors.

A compact, inexpensive motor for garage doors up to 7m², providing a speed up to 14cm/s. The Somfy Dexxo Compact motor comes with 2 Keytis RTS remote controls, which can each command 2 different Somfy products, helping you harmonise your Somfy living convenience.

Benefits Quick and easy to install, even easier to use. The Dexxo RTS range is perfect for both you and your customers.	Installer Benefits Dexxo is quick and simple to install. Its setting and diagnostics are user-friendly and clear, and can be accessed easily to save you time in set-up and maintenance.
Plug & play system The motor has built-in safety features – so no requirement for a safety edge. Compatible with all other Somfy products. Quick connect: mains supply cable, motor and accessories.	Quick & simple installation Simple, quick and intuitive 90 second set up. Real-time feedback during the commissioning phase. Adjustable pre-programmed settings. Motor direction/limit settings completed from the control panel.
Real time diagnostics Motors provide real-time status. Motor thermal and safety brake status. Additional photo cell options. Back up battery & battery power options available.

Power supply	230 V - 50 Hz
Standby power consumption	4 W
Max. power consumption	120 W
Tensile force - Maximum force	600 N
Operation	20 cycles per day (tested for 10000 cycles)
Number of storable channels	32
SOMFY radio frequency	433.42 MHz RTS
Integrated lighting	24 V 20 W G4 socket halogen bulb
Operating temperature	-20°C / +60°C
Electrical insulation	Class 2 double insulation
Index of protection	IP20
Safety inputs	Dry contact NC
Photoelectric	TX/RX cells
Wired control input	Dry contact input N/O
Maximum opening speed	14 cm/s
Maximum closing speed	12 cm/s
End limits	Mechanical stop when opening, electronic when closing: stored closing position
Accessories supply output	24 V - 500 mA max
Forced operating mode	By pressing and holding button “A”
Timed lighting (after movement)	Fixed: 30 s
Integrated obstacle detection	Adjustable sensitivity: 4 levels
Operation in the event of obstacle detection	Total reopening
Gradual starting	Yes
Motor warranty	5 years
