Somfy Dexxo Pro 1000 RTS

Garage door opener specifications:

Max garage door height depends on boom selected
Max garage door surface 15 m²

Included:

Two handsets

SKU: SOO9710 Categories: Garage Door Openers, Manufacturers, New Products, Products, Somfy, Somfy, SWS SeceuroGlide Tag: Bulky

Description
Features
Additional Technical Information
Downloads

Description

Somfy Dexxo Pro 1000 RTS

The premium, powerful and fast motorisation for all types of garage doors.

Somfy’s top-of-the range system can open garage doors up to 15m² providing a speed up to 18cm/s, and offers a range of handy features to accommodate your personal preferences.

Smooth, silent and quick; both the Dexxo Pro 1000 offers the possibility to connect an external light source and an alarm buzzer. The Somfy Dexxo Pro 1000 RTS motor comes with 2 KeyGo RTS remote controls, which can each command up to 4 Somfy RTS products, helping you harmonize your Somfy living convenience.

Benefits Quick and easy to install, even easier to use. The Dexxo RTS range is perfect for both you and your customers.	Installer Benefits Dexxo is quick and simple to install. Its setting and diagnostics are user-friendly and clear, and can be accessed easily to save you time in set-up and maintenance.
Plug & play system The motor has built-in safety features – so no requirement for a safety edge. Compatible with all other Somfy products. Quick connect: mains supply cable, motor and accessories.	Quick & simple installation Simple, quick and intuitive 90 second set up. Real-time feedback during the commissioning phase. Adjustable pre-programmed settings. Motor direction/limit settings completed from the control panel.
Real time diagnostics Motors provide real-time status. Motor thermal and safety brake status. Additional photo cell options. Back up battery & battery power options available.

Power supply	230 V - 50 Hz
Standby power consumption	5 W
Max. power consumption	600 W (with 500 W remote controlled lighting)
Tensile force - Maximum force	1000 N
Operation	20 cycles per day with a standard rail (tested for 36,500 cycles)
Number of storable channels	32
SOMFY radio frequency	433.42 MHz RTS
Integrated lighting	24 V 21 W max BA15s socket
Operating temperature	-20°C / +60°C
Electrical insulation	Class 2 double insulation
Index of protection	IP20
Safety inputs	Dry contact NC
Photoelectric	TX/RX cells
Wired control input	Dry contact input N/O
Opening speed	Programmable from 3.5 cm/s to 18 cm/s: 10 possible values
Closing speed	Programmable from 3.5 cm/s to 18 cm/s: 10 possible values
Programming interface	7 buttons - 2 character LCD display
End limits	Mechanical stop when opening, electronic when closing: stored closing position
Accessories supply output	24 V - 500 mA max
Forced operating mode	By pressing and holding the motor control button
Timed lighting (after movement)	Programmable : 60 s to 600 s
Automatic closing mode	Yes: programmable closing time delay from 10 to 120 s
Integrated obstacle detection	Adjustable sensitivity: 4 levels
Operation in the event of obstacle detection	Programmable : partial re-opening or full reopening
Preset partial opening command	Yes can be selected: adjustable partial opening position
Gradual starting	Yes
Motor warranty	5 years
